TED200C 12 W Laser Diode Temperature Controller
Brand: ThorLabs | Category: Scientific & Laboratory Equipment
A precision temperature controller driving thermoelectric elements up to 2 A, with separate P, I and D adjustment for fast settling. It is used to stabilise laser diodes for interferometry and spectroscopy, cool detectors and hold nonlinear crystals at temperature.
Technical Specifications
| Parameter | Value |
|---|---|
| TEC current control range | -2 A to 2 A, maximum output power 12 W |
| Compliance voltage | greater than 6 V |
| Temperature stability over 24 hours | less than 0.002 degrees C with IC sensors |
| Thermistor control ranges | 10 ohms to 20 kilohms and 100 ohms to 200 kilohms |
| Supported IC sensors | AD590, AD592, LM135 and LM335 |
| Control range with AD590 or LM135 | -45 to 145 degrees C |
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Intended application, process or teaching activity
- Required capability and equipment it must work with
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about ThorLabs equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
