TTC001 T-Cube TEC Controller
Brand: ThorLabs | Category: Scientific & Laboratory Equipment
A compact microcontroller based PID temperature controller for driving a Peltier element against a thermistor or IC sensor. It suits stabilising small temperature sensitive components on a bench and can be run locally or from a PC over USB.
Technical Specifications
| Parameter | Value |
|---|---|
| TEC output | plus or minus 1 A and 4 W maximum |
| Maximum output voltage | 4 V |
| Compatible sensors | 20 k and 200 k thermistors, AD590 and AD592 |
| IC sensor control range | -45 to 125 degrees C |
| Temperature stability over 24 hours | less than 0.5 degrees C with IC sensors |
| Housing | 60 mm x 60 mm x 47 mm, weight 160 g |
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Intended application, process or teaching activity
- Required capability and equipment it must work with
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about ThorLabs equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
