MEBM: Euler Buckling Modes Unit
Brand: EDIBON | Category: Scientific & Laboratory Equipment
MEBM allows the higher buckling modes of a slender strut to be produced and observed. Intermediate supports are added along the specimen so the second and third mode shapes appear, with the corresponding critical loads measured.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 420 x 460 x 730 mm approx |
| Weight | 5 Kg approx |
| Four elastic bars length | 180 mm |
| Four elastic bars cross-section | 0.5 x 10 mm |
