MES: Simple Balancing Unit
Brand: EDIBON | Category: Scientific & Laboratory Equipment
MES is a basic unit for balancing rotating masses in a single plane. Known masses are fixed at different radii and angles on a disc and the required balancing mass is then determined experimentally and by calculation.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 450 x 550 x 600 mm. approx |
| Weight | 25 Kg approx |
| Specification | Electrical motor with variable speed which can reach 8300 rpm |
| Specification | Aluminum external disc, that we will name graduated disc. It has a diameter of 150 mm |
