MGTA: Gear Train Assembly Unit
Brand: EDIBON | Category: Scientific & Laboratory Equipment
MGTA is used to assemble simple, compound and reverted gear trains on a slotted plate. Students calculate train values, verify them by counting revolutions and study the direction of rotation in each arrangement.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 1100 x 550 x 500 mm approx |
| Weight | 75 Kg approx |
| Specification | Straight gears module m= 2; number of teeth z= 20, 24, 30, 32, 36, 40, 45, 50, 60, 80, 95 |
| Specification | Straight gears module m=1.5; number of teeth z= 60, 70, 80, 90 |
| Endless screw gear helical wheel | module m= 3.15; number of teeth z= 62 |
