Model 800D Series Electrochemical Detector
Brand: CH Instruments | Category: Nanotechnology
The 800D series is built for electrochemical detection, monitoring current through a flow cell in liquid chromatography or flow injection analysis. Its low noise circuitry measures down to picoamperes and plots three decades of current scale during a run. The 8x2D models add a bipotentiostat for dual channel work.
Technical Specifications
| Parameter | Value |
|---|---|
| Maximum potential | +/-10 V for both channels |
| Maximum current | +/-10 mA |
| Measured current range | +/-10 pA to +/-0.001 A in 9 ranges |
| Galvanostat applied current range | 3 nA to 10 mA |
| CV and LSV scan rate | 0.000001 to 5 V/s |
| Fast data acquisition | 16 bit ADC, 1,000,000 samples per second |
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Materials, sample dimensions and process or measurement goal
- Required performance and existing instrument interfaces
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about CH Instruments equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
