MSDA: Simple Drives Assembly Unit
Brand: EDIBON | Category: Scientific & Laboratory Equipment
MSDA is a kit for assembling and testing simple mechanical drives such as belt, chain and gear transmissions. Students mount each drive on a common frame and compare speed ratio, slip and efficiency between the arrangements.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 800 x 500 x 300 mm approx |
| Weight | 30 Kg approx |
| Specification | Simple straight gears module m= 2; number of teeth z= 30, 60 |
| Specification | Pair of bevel gears module m= 2; number of teeth z = 26 |
