MVV: Unsymmetrical Cantilever Unit
Brand: EDIBON | Category: Scientific & Laboratory Equipment
MVV is used to study the bending of a cantilever whose section is not symmetrical about the load plane. The beam can be rotated about its axis and deflection measured in two directions, showing how the principal axes govern the deflected shape.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 400 x 300 x 400 mm approx |
| Weight | 14 Kg approx |
| Specification | Two dial gauges of 0 to 25 mm and 0.01 mm accuracy, to measure u and v deflections |
