Passive Isolation Optical Table Supports
Brand: ThorLabs | Category: Scientific & Laboratory Equipment
Pneumatic table legs that isolate an optical table from floor vibration across the 10 to 50 Hz range where most laboratory disturbance sits. The closed oil-free system is inflated with a foot pump and needs no permanent compressed air supply.
Technical Specifications
| Parameter | Value |
|---|---|
| Vertical resonant frequency | 4.42 Hz |
| Vertical transmissibility at 10 Hz | -11.5 dB (74%) |
| Load capacity, standard, set of four | 275 to 1100 kg |
| Load capacity, heavy duty, set of four | 550 to 2400 kg |
| Heights | 600 mm (23.6") or 700 mm (27.6") |
| Recommended air pressure | 65 to 75 psi (448 to 517 kPa) |
