Upgradeable Optical Table Supports: Rigid, Non-Isolating
Brand: ThorLabs | Category: Scientific & Laboratory Equipment
Free-standing rigid legs for Thorlabs optical tables, supplied in three heights with a levelling pad. They suit vibration-insensitive work such as general spectroscopy, and each leg can later be converted to passive pneumatic isolation with an upgrade kit.
Technical Specifications
| Parameter | Value |
|---|---|
| Heights | 450 mm, 600 mm or 700 mm |
| Height adjustment | plus 15 mm, minus 8 mm |
| Maximum load capacity for a set of four | 2500 kg (5500 lbs) |
| Levelling range | 23 mm (0.90") using the included wrench |
| Specification | Upgradeable to passive isolation with the PWA076 kit |
| Specification | Compatible with all Thorlabs optical tables |
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Intended application, process or teaching activity
- Required capability and equipment it must work with
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about ThorLabs equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
