SOM® 62 Pro ENT motorised
Brand: Karl Kaps | Category: Medical Equipment
Built for ENT clinics and surgical centres, the Pro ENT motorised combines an apochromatic motorised 1:6 zoom with motorised fine focusing so sharpness can be set to the millimetre from a handle button or footswitch. The motorised vario lens covers a working distance of 200 mm to 400 mm without objective changes, which saves time and protects sterility in the surgical field. Electromagnetic Free Motion brakes release at the press of a handle button and lock the head again the moment it is let go, with mechanical balancing keeping movement even when cameras or observer optics are fitted. Integrated LED illumination of roughly 50,000 hours runs quietly and without noticeable heat, with cold light or xenon available as options.
Selected manufacturer specifications
| Parameter | Value |
|---|---|
| Motorised working-distance range | 200–400 mm |
| Zoom and focus | Motorised |
| Positioning | Magnetic brakes |
| Controls | Handgrip or foot control panel |
Selected information from this Karl Kaps product page. Confirm compatibility, optical configuration and optional accessories in the quotation; related-product listings are not specifications for this item. Checked 2026-09-29.
Confirm your configuration
Share the details you know so we can prepare a comparable, itemised offer.
- Specimen or clinical application and required imaging/measurement outputs
- Optics/source, detectors, working distance, stage and documentation options
- Room conditions, utilities, preparation accessories and operator training
Get a Quote
Request an itemised quotation covering the proposed configuration, availability, lead time and agreed supply and support scope.
Useful details to share
- Clinical, training or facility application
- Required configuration, accessories and existing equipment
Share what you know. You can start with your name and a phone number or email; final specifications can follow.
Not sure which configuration you need? Help me choose
Contact Vvon Technologies Limited about Karl Kaps equipment requirements in Bangladesh.
Phone: +8801805987890 | Email: info@vvon.com.bd
