STH: Stress Hypotheses Unit
Brand: EDIBON | Category: Scientific & Laboratory Equipment
STH allows combined loading of a thin walled tube so that different failure theories can be compared. Internal pressure, axial load and torque are applied together and the resulting strains are measured with bonded gauges.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 460 x 460 x 420 mm approx |
| Weight | 20 Kg approx |
| Specimen diameter in the measuring section | 4 mm |
| Measuring range | 0 to 10 mm |
| Graduation | 0.01 mm |
