Temperature Controller CH1
Brand: Nanosurf | Category: Nanotechnology
A temperature controller for Nanosurf sample holders with variable temperature. It reads two sensors, a PT100 for control and an NTC for monitoring, and drives both resistive and Peltier based heating elements.
Technical Specifications
| Parameter | Value |
|---|---|
| Temperature stability | better than 0.05 degrees C |
| Compatible sensors | PT100 for control, NTC for monitoring |
| Maximum output | 20 V and 10 A |
| Dimensions | 220 x 45 x 270 mm |
| Weight | 1.5 kg |
| Compatibility | DriveAFM, FlexAFM, CoreAFM |
