TFC: Computer Controlled Francis Turbine
Brand: EDIBON | Category: Scientific & Laboratory Equipment
TFC is a computer controlled Francis turbine test set. Guide vane position, head, flow, speed and torque are logged so the power and efficiency curves of the mixed flow machine can be built up across its operating range.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 800 x 900 x 800 mm approx |
| Weight | 75 kg approx |
| Diameter of the turbine | 52 mm |
| Speed range | 0 to 1200 rpm approx |
| Maximum pressure | 7 bar |
| Maximum water flow | 160 l/min |
