TKC: Computer Controlled Kaplan Turbine
Brand: EDIBON | Category: Scientific & Laboratory Equipment
TKC is a computer controlled Kaplan turbine test set. Runner blade angle, head, flow, speed and torque are logged so students can study how the blade setting affects power output and efficiency over the operating range.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 800 x 900 x 1100 mm approx |
| Weight | 75 Kg approx |
| Speed range | 0 to 2500 rpm |
| Diameter of the turbine | 52 mm |
| Maximum pressure | 2.2 bar |
| Maximum water flow | 120 l/min |
