TFRC: Computer Controlled Radial Flow Turbine
Brand: EDIBON | Category: Scientific & Laboratory Equipment
TFRC is a computer controlled radial flow turbine test set. Head, flow, speed and torque are logged through the data acquisition system so the characteristic and efficiency curves of the reaction machine can be plotted.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 800 x 900 x 800 mm approx |
| Weight | 100 kg approx |
| Nozzle inlet diameter | 21 mm |
| Nozzle outlet diameter | 2 mm |
| Turbine rotor external diameter | 69 mm |
| Turbine rotor internal diameter | 40 mm |
