VisIR
Brand: PicoQuant | Category: Nanotechnology
VisIR is a stand-alone picosecond laser for the infrared, with wavelengths available from 765 to 1950 nm and a spectral width well below 1 nm. Internal repetition rates are selectable between 31.25 kHz and 80 MHz, and external triggering runs from below 1 Hz to 80 MHz. It is used for STED, LiDAR and materials research.
Technical Specifications
| Parameter | Value |
|---|---|
| Available wavelength | 765 to 1950 nm |
| Spectral width | << 1 nm |
| Repetition rates (internal) | user selectable 80, 40, 20, 10, 5 or 2.5 MHz (80 MHz base frequency), or 1 000, 500, 250, 125, 62.5 or 31.25 kHz (1 MHz base frequency) |
| Repetition rates (external via NIM or TTL input) | < 1 Hz to 80 MHz |
| Polarization Extinction Ratio (PER) | > 1:1000 (> 30 dB) for VisIR-765(-HP), > 1:60 (> 18 dB) for VisIR-1064, > 1:100 (> 20 dB) for VisIR-1530/1550(-HP) |
| Dimensions | 352 × 336 × 82.5 mm (l × w × h), weight 6.5 kg |
